| DESCRIPTION | Unit | Data | |
|---|---|---|---|
| Mounting Truck | ton | 4.5 GVW | |
| Max.working floor of building | fl | 9 | |
| Max. Height | m | 25 | |
| Product’s Dimension (with Vehicle) |
Length | mm | 5,200 |
| Height | mm | 1,740 | |
| Width | mm | 2,600 | |
| Power | Engine | P.T.O | |
| Turntable | Rotation Angle | deg. | ±135 |
| Type | By hydraulic reduction gear | ||
| Boom | Number of booms | 7 | |
| Material | High tension, aluminum alloyed |
||
| Extension | By wire main/supplementary : 8mm |
||
| Lifting Conveyance | Dimension | mm | Basic : 1,300*1,000*520 |
| Extended : 2,220*1,470*70 | |||
| Angle control | by one touch | ||
| Max. working load | kg | 350 | |
| Max. operation speed |
Boom’s extension/retraction |
m/m | within 24 |
| Outrigger | Type | H-TYPE | |
| Extension | Slide ~ Manual Jack ~ Hydraulic Cylinder |
||
| Max. Extension | mm | 3,650 | |
| Remote control | Type | Dial(wired, wireless) | |
| Function | Automatic conveying | ||
| Safety system | Hydraulic check valve, Solenoid valve, Emergency stop, Sensor of over load, Sensor of speed reducing area, Warning system of max. height, Protection system for over turn. | ||
The above specifications are bound to change without prior notification for better operators safety and due to changes in truck specifications.
